Home > Specs > Peugeot > XN1P | Notes | Prices |
4 cyl | XN1P | 1971 cc |
Xnipec Salsa
BORE | STROKE | FIRING | MAIN | ROD |
ORDER | JOURNAL | JOURNAL | ||
3.4650 | 3.1890 | 1-3-4-2 | See Below | 1.9685 |
SPARK PLUG | SPARK PLUG | SPARK PLUG | IGN.TIMING | OIL CAPACITY |
TYPE | GAP Gas/Dual | GAP LPG | IDLE SPEED | WITH FILTER |
W16EX-U | 0.024 | .016-.020 | 8 deg.BTDC/850 | |
TORQUE VALUES | ||||
LOCATION | FT. LB. | LOCATION | FT. LB. | |
Main brg.caps | 55 | Oil pan drain plug | 26-30 | |
Rod brg.caps | 29 | Oil pump bolt | 90 in,lbs. | |
Cyl. head bolts | 60 | Rocker arm nut | 90 in,lbs. | |
Cam sprocket bolt | 16.6 | Rckr.shaft brckt.bolt | ||
Crank pulley bolt | 125 | Timing cover | 90 in,lbs. | |
Flywheel bolt | 50 | Spark plug | 16.5-18 | |
Flywheel housing | Water outlet bolt | |||
Manifold bolt & nut | 15-18 | Water pump bolt | ||
Oil pan bolt | 90 in.lbs. | Wtr.pmp.pulley bolt | ||
PISTON | ||||
Sleeve clearance | .0024-.0031 | |||
RINGS | ||||
Ring gap-Top | .0079-.0197 | Side clearance Top | ||
Ring gap-2nd | .0157-.0217 | Side clearance 2nd | ||
Ring gap-Oil | .0098-.0157 | Side clearance Oil | ||
CRANKSHAFT | ||||
Front M/journal | 2.3386-2.3392 | Rod journal dia. | 1.9679-1.9685 | |
Front Interior | 2.3050-2.3060 | Rod run clearance | .0007-.0020 | |
Center | 2.2509-2.2515 | Main run clearance | .0010-.0030 | |
Rear Interior | 2.2102-2.2112 | End play | .003-.008 | |
Rear M/journal | 2.1616-2.1622 | T/washer thickness | .090 to .098 | |
CAMSHAFT | ||||
Front journal dia. | 1.8864-1.8874 | End play | .002-.0055 | |
Center journal dia. | 1.8077-1.8087 | |||
Rear journal dia. | 1.7289-1.7299 | |||
VALVES | ||||
Intake length | 4.656 | Exhaust length | 4.409 | |
Intake stem dia. | 0.3158 | Exhaust stem dia. | 0.3157 | |
Intake head dia. | 1.6733 | Exhaust head dia. | 1.3977 | |
Intake face angle | 45 deg. | Exhaust face angle | 45 deg. | |
Intake clearance | .004-.006 cold | Exhaust clearance | .010-.012 cold |
